The GX160 offers improved fuel economy, lower noise levels, lower vibration, and lower emissions – without sacrificing power output or performance. The current GX160 essentially matches the dimensions of previous models, so no modifications to existing equipment designs are necessary.
Common Applications:
Dimensions LxWxH: 31.2cm x 36.2cm x 34.6cm (12.2" x 14.3" x 13.6")
- Pressure washers
- Commercial lawn and garden equipment
- Tillers/cultivators
- Generators
- Construction/industrial equipment
- Agricultural equipment
- Water pumps
Features:
- New design offers even better fuel economy than before!
- Precision camshaft design offers precise valve timing and optimal valve overlap for better fuel efficiency
- OHV design for increased efficiency and optimal power transfer
- High compression ratio for better fuel efficiency
- Precision-engineered components result in lower vibration
- Reduced piston weight and precision balanced crankshaft result in lower engine vibration
- Ball bearing supported crankshaft for greater stability
- luminum push rods reduce both valve clearance and noise level
- New enhancements to the muffler, breather valve, and case cover reduce noise level
- Reduced mechanical noise due to light weight, noise-reducing materials
- Forged steel crankshaft and rigid crankcase
- Helical cut gears
- Sophisticated air intake system
- New carburetor chamber coating and carburetor filter help to protect against fuel impurities
- Cast iron cylinder sleeve
- High-quality materials, fit, and finish
- Dual element air cleaner
- Fuel Valve
- Simple throttle control
- Large fuel tanks
- Large automotive type fuel cap
- Dual oil drains and fill
- Easy, convenient, heavy duty control box
- Easily accessible spark plug
- Heavy-duty recoil starter
- Lower emissions, higher power output!
- CARB and EPA certified
- No catalyst necessary
Engine Type: Air-cooled 4-stroke OHV
Bore x Stroke: 68mm x 45mm
Displacement: 163cc
Compression Ratio: 9.0:1
Fuel Tank Capacity: 3.1L (3.3 US qts)
Starting System: Recoil Start
Oil Capacity: 0.58L (0.61 US qts)
Dry Weight: 15.1kg (33lbs)
